Fig. 7

Download original image
(a) Cross-sectional SEM image of the SiNT fabricated on the bare-Si substrate and the inset is the top-view image. (b) Prototype and spatial configuration of the SiNT-based STM. (c) The THz time-domain spectrum of the bare Si wafer and SiNT samples with different length. [55]
